AID
Industrial Dispenser
16, 24, 32…96 materials or more for customization Apply to industry of paint & coatings, ink printing, auxiliary chemicals, food, leather, cosmetics, etc.
FEATURES
Automatic dispensing
Adopt weighing feedback system with high precision, the accuracy is up to ±0.1g
Automatic formula reading
Automatic filling materials according to formulas, avoid mis-filling.
Connect with client's ERP/MES system directly
Automatic data feedback; Improved factory informatization; Accurate statistics of material consumption.
Match with spectrophotometer
Available data of color matching software for production.
PARAMETERS
| Efficiency | 20kg/3min (3-4 kinds of materials) |
| Accuracy | 30kg/1g（10kg/0.1g optional) |
| Air Source Pressure | 0.6 Mpa |
| Weighing Scope | 5kg、10kg、30kg…1000kg、1500kg、2000kg、3000kg |
| Power Supply | 220V/110V 50Hz/60Hz |
| No. of Canisters | 12、16、24、32…96(customizable) |
| Weighing Sensor | Mettler-Toledo/Flintec |
| Filling Valve | Three-section high accuracy valve |
| Diaphragm Pump | ARO |
| Industry | Paint & coatings, ink printing, auxiliary chemicals, food, leather, cosmetics, etc. |
